Accelerate your projects
Design the hot runner for your application yourself for fast configuration and immediate design delivery!
-
-
Application check
Go ahead and try it! We check your application and offer guidance when critical values are reached.
-
Expert supportIf you have any questions, our global expert team will help and support you.
How it works
-
1 | RegisterSign up to get started
-
2 | Configure
Follow the easy configuration guide
-
3 | Get EmailGet your 3-D data within a few minutes
Fits Perfectly Into Your Mold Design.
The Side Gate Nozzle is available in various sizes to accommodate different part volumes.
This allows for adaptation to various part geometries and shot weights.
-
-
Radial Version- 1, 2, 4 or 8 nozzle tips.
- Versatile layout of the injection points.
- The single tip version allows extreme design flexibility.
-
Linear Version- 2+2 or 4+4 parallel nozzle tips.
- Minimal gate point spacing of 16 mm.
- Particularly suitable for applications requiring multiple injection points in a row.
Easy Maintenance.
Since side gate nozzles protrude into the mold insert, it is crucial for the user to know how challenging the disassembly is during maintenance or when a fault occurs. Eight minutes—that's how quick the time is to change a nozzle insert, with the mold remaining on the machine. And if ever necessary, a cavity can be shut down just as quickly and easily to keep production interruptions as short as possible.
-
Signature Line
Featuring the Original Männer Valve Gate Technology.
The Signature Line stands for tailored solutions and uncompromising durability. Equipped with Original Männer Cylindrical Valve Gate Technology, these systems impress with advanced design and the highest manufacturing precision. They enable dependable operation over many years – even in high-cavitation molds and extremely long production cycles.
Outstanding gate quality, consistent part-to-part accuracy, shortest cycle times, and absolute process stability make the Signature Line the first choice for long-term series production of large quantities.
-
%20(1).png)
New Performance Line
Featuring Barnes Molding Solutions Technology.
The new Performance Line is the result of nearly a decade of dedicated development within the Molding Solutions Group and offers a comprehensive, cost-efficient nozzle portfolio. It includes open hot runner systems, valve gate systems, and side-gating solutions. With a broad selection of nozzle types, lengths, tips, and manifold sizes, the Performance Line provides the right solution for almost any challenge.
Designed for medium- to high-cavitation molds and products with a medium lifecycle, it delivers reliable gate quality combined with an attractive price-performance ratio.
Unlocking More Value for Your Production Line
-
Hot Runner RefurbishmentHot runner systems are the heart of efficient injection molding — but even the best equipment wears over time. Our refurbishment service restores worn or damaged components to optimal condition, ensuring precise temperature control, improved flow, and consistent product quality. Avoid unplanned downtime and costly replacements while keeping your production running smoothly.
-
Hot Runner TrainingOur two-day training program combines in-depth theoretical instruction with hands-on practice directly in the workshop. It is designed for professionals who want to understand not only the principles of hot runner systems, but also how to install, maintain, and service them effectively.
From Fundamentals to Practical Expertise!
-
Hot Runner Control SystemsPrecise temperature management is the key to producing consistent, high-quality parts while keeping scrap rates low and profitability high.
Our advanced Gammaflux control systems deliver unmatched accuracy, stability, and user-friendly operation. With intelligent temperature monitoring and adaptive control, you can ensure optimal melt flow, reduce downtime, and increase the overall efficiency of your production process.
Whether you’re running small-scale projects or high-cavity, high-volume production, Gammaflux technology provides the precision and reliability you need to take full control of your hot runner system.
-
.jpg)
Medical Day 2025Medical Day 2025 brought together brilliant minds, inspiring speakers, and a passionate community dedicated to shaping the future of healthcare. From thought-provoking talks to lively networking moments, the day was filled with energy and ideas. Here’s a look back at some of the highlights.
We offer the right refurbishment package –
tailored to your mold's needs.
Whether your mold requires only minor adjustments or a full mechanical and functional overhaul: we offer a flexible range of refurbishment solutions to match your goals, timeline, and budget. All packages are carried out by experienced tooling experts using OEM-level standards and documentation. Planned refurbishment reduces unexpected downtime, lowers total cost of ownership, and keeps your production running efficiently.
-
Mold Refurbishment Light PackageOur Light Package focuses on essential components to restore reliable performance with minimal downtime:
-
Full refurbishment of the hot runner system
-
Replacement of guiding and centering elements for FH & MH (AS & DS)
-
Warranty renewal of the hot runner system in accordance with Otto Männer GmbH’s general terms and conditions
This package is ideal for molds still in good condition that require targeted maintenance to ensure consistent part quality and continued process stability.
-
-
Mold Refurbishment Full PackageOur most comprehensive package restores your mold to peak performance – ideal for extending lifecycle and maximizing output reliability:
-
Complete replacement of cavity stacks
-
New guiding and centering elements
-
Replacement of all wear and tear parts
-
Full cleaning and inspection of the entire mold
-
Final Operational Test (FOT) to validate performance
-
Warranty renewal with 50% of the original new mold conditions – minimum 1 million cycles guaranteed
This package is recommended when a mold shows extensive wear or reduced precision. It offers a cost-efficient alternative to new mold investment, with high functional reliability.
-
-
.png)
Mold Refurbishment Custom PackageTailored refurbishment after a comprehensive mold assessment – based on the exact condition and requirements of your mold.
-
On-site assessment by our experts
-
Customized quotation based on actual wear and condition
-
Refurbishment performed at the MS mold plant, using OEM standards
-
Final Operational Test (FOT) ensures mold readiness
-
Warranty renewal after full refurbishment with 50% of the original warranty conditions – minimum 1 million cycles
Cost transparency & value-added:
-
Refurbishment > €100k → 50% reimbursement of the assessment costs
-
Refurbishment > €200k → 75% reimbursement of the assessment costs
Optional add-ons:
-
Spare parts packages (mold / hot runner)
-
Stand-alone repairs of damaged components (if feasible)
-
Modifications to meet new production or product requirements
This package is ideal for complex, high-value molds where a detailed condition-based approach ensures maximum return on investment.
-
-
Cube Mold Refurbishment ETW PackagePlanned hot runner maintenance can reduce downtime by up to 70%.
-
Mold & Hot Runner Refurbishment Spare Parts AgreementAlways Ready, Always Reliable: A spare parts agreement with Männer or Foboha ensures that essential components are always available to keep your molds running smoothly. By securing predefined parts in advance, you minimize downtime and increase efficiency.
Your benefits at a glance:
-
Rapid availability
Immediate access to critical spare parts – less unplanned downtime, better service performance. -
Cost efficiency
Attractive long-term conditions and pricing through fixed contracts. -
Planning reliability
Simplified scheduling of maintenance and repairs with assured parts supply. -
Lower administrative effort
Reduce time and resources needed for sourcing and procurement - Storage costs are covered by Männer/Foboha
-
-
